Svalson Sliding Window model Njord Thermo

Sliding Window model NJORD THERMO

Sturdy, vertically sliding window with thermally insulated profiles. The sliding window has a 120* mm aluminium frame and can be equipped with insulating glass or up to 26 mm thick safety glass. Njord Thermo can be produced with two, three or more moving sections, so that the largest possible part of the opening can be put to use. Opening of the sliding window is either downward or upward (standard). In its standard version, the sliding window is satin anodized and is equipped with D4-15 double glazing. The frame can be finished by painting, powder coating or other forms of anodizing. The sliding window is equipped with a safety latch which prevents the window from dropping in the event of an accident. Njord Thermo can be delivered with either electrical or manual operation. With electrical operation, the sliding window is automatically locked in the closed position. Control is by means of a control box or pedal.

Examples of versions


Window with two sections	Window with three sections	Window with four sections

Opening downwards	Opening downwards	Fixed glass section below the window

Fixed aluminium section below the window	Fixed aluminium section above the window	Fixed window

Technical information

Width		Customers choice.
Height		Customers choice.
* Frame thickness		120 mm or more depending on version.
Width of side posts		80 mm.
Height of top profile		80 mm.
Height of bottom profile		No information
Width/Height of glass frames		35 mm.
Construction		Electrically driven: Motor, transmission, safety latch and automatic locking are integrated within the frame. Manually driven: Safety latch is integrated within the frame.
Locking		Electrically driven: Mechanical lock which automatically locks the window in closed position and at 50 mm intervals across the entire opening height. Key lock is optional. Manually driven: Key lock ASSA 13787 integrated into the bottom profile. If the window is manufactured without the bottom profile, the ASSA 13787 can not be used. Other solutions might be possible.
Motor		Electrically driven: 24 V DC. Manually driven: No.
Transmission		Cord.
Traction force		Electrically driven: Approx. 40 N. Manually driven: Low.
Relief for transmission		Friction clutch.
Power supply		Electrically driven: Transformer. Battery back-up is optional. Manually driven: No.
Type of control		Electrically driven: Manoeuvre box. Foot switch is optional. Manually driven: Handle.
Glass		D4-15 double glazing is standard. Other glass up to 26 mm thick is available as an option.
Finish		Satin anodized (minimum 10 µm) aluminium is standard. Other surface finishes available as an option include powder coating, painting or anodizing in various colours.
Protection against fire		No.
Alarm device		Optional.
Design and material subject to change without prior notice.
