Sliding Window model 9018

Sturdy, vertically sliding window for wide openings. Suitable for both indoor and outdoor installation. The sliding window has a 90* mm aluminium frame and can be equipped with insulating glass or up to 20 mm thick safety glass. The 9018 model can be produced with two, three or more moving sections, so that the largest possible part of the opening can be put to use. In its standard version, the sliding window is satin anodized and is equipped with D4-12 double glazing.

The frame can be finished by painting, powder coating or other forms of anodizing. The sliding window is equipped with a safety latch which prevents the window from dropping in the event of an accident. The sliding window is automatically locked in the closed position and at intervals across the entire opening height. Control is by means of a control box or pedal.

Examples of versions


Window with two sections	Window with three sections	Window with four sections

Fixed glass section below the window	Fixed aluminium section below the window	Fixed aluminium section above the window

Fixed window

Technical information

Width		Customers choice**.
Height		Customers choice.
* Frame thickness		90 mm with one movable section, 120 mm with two movable sections and 150 mm with three movable sections. Please get in touch with our sales personnel for further information on windows with more than three movable sections.
Width of side posts		60 mm.
Height of top profile		70 mm.
Bottom profile		No.
Width/Height of glass frames		30 mm.
		** If the width of the window exceeds 2000 mm we recommend model NJORD instead.
Construction		Motor, transmission, safety latch and automatic locking are integrated within the frame.
Locking		Mechanical lock which automatically locks the window in closed position and at 50 mm intervals across the entire opening height. Key lock is optional.
Motor		24 V DC.
Transmission		Cord.
Traction force		Approx. 20 N.
Relief for transmission		Friction clutch.
Power supply		Transformer. Battery back-up is optional
Type of control		Manoeuvre box. Foot switch is optional.
Glass		D4-12 double glazing is standard. Other glass up to 20 mm thick is available as an option, such as 16 mm thick class B1 impact-resistant laminated glass.
Finish		Satin anodized (minimum 10 µm) aluminium is standard. Other surface finishes available as an option include powder coating, painting or anodizing in various colours.
Protection against fire		No.
Alarm device		Optional.
Design and material subject to change without prior notice.
