Palazzo® M8

Palazzo M8 is supported by a rotation-proof octagonal pole that makes it particularly tough. The cover can be easily re-tautened with the variable rod extensions. The hand crank or the optional motor make it possible to open the Palazzo M8 in an easy and comfortable way. The sunshade canopy opens and closes over tables and chairs by means of the counterrotating principle (servo principle). In addition, you can benefit from a longer outdoor season thanks to special lighting and/or heating elements.

icMaterials and technology: The frame is made of pressed aluminium profiles. Every single part has anti-corrosion properties and can be replaced individually. The Palazzo M8 has been passed for use by TÜV.

icHow to operate: The sunshade can be opened or closed using the hand crank or the optional motor, with or without remote control.

icWinter storage: Store it on the spot in its protective cover, secured against the wind, or dismantled, in a dry and sheltered place

icWind safety: The max. wind speed limits as per our separate list apply only if there is a fix ground anchorage.

icAdvertising imprint: Individual imprints on shade roof and/or flounces are possible.


icFixing options: 230 kg base (4 concrete slabs) with support tube, 430 kg base (8 concrete slabs) with support tube, 580 kg base (12 concrete slabs) with support tube, ground socket and support tube with centering device, ground socket with tip-over hinge, various mounting plates with support tube or tip-over hinge allowing a whole lot of different mounting methods.

icAccessories: Protective cover, curtain, rain gutter.

icElectric accessories: Motor drive with control unit, remote control for motor drive, anemometer, key switch (surface or flush mounted). Electric kit, 400 V (3PNE), 13 A for lighting 230 V, 4 x 16 W, and/or radiant heater 1500 W, 230 V, 6.5 A (max. 4 radiant heaters for each sunshade).
Palazzo
Palazzo
Palazzo
 Palazzo
Pole profile
230 kg shade base
(4 concrete slabs),
430 kg shade base
(8 concrete slabs),
support tube
580 kg shade base
(12 concrete slabs),
support tube 		Ground socket,
support tube with
centering device
Palazzo
Palazzo
Palazzo
 Palazzo
Ground socket,
tip-over hinge
Mounting plate,
support tube
Mounting plate,
tip-over hinge
Example: Mounting plate
special, for installation
height 150 – 350 mm,
support tube
Palazzo
Palazzo
Palazzo
Palazzo
Protective cover
Rain gutter of polyester
fabric PVC-coated
on both sides
Curtain
Control unit, motor drive,
key switch, anemometer
Palazzo Palazzo
Palazzo
Palazzo
Remote control,
key switch
Electric kit
Lighting
Heat transmission
max. 4 pieces per sunshade

icMaterial qualities and colours

Material class 5
100 % acrylic approx. 300 g/m2 colours 500 - 699
Sun protection factor UPF 50+

icSizes and weights

8 piece round ø 450 / 500 / 550 / 600 cm
12 piece round ø 600 / 650 / 700 / 750 cm
8 piece square 400 x 400 / 450 x 450 / 500 x 500 cm
12 piece square 500 x 500 / 550 x 550 / 600 x 600 cm
8 piece rectangular 450 x 350 / 500 x 400 cm
12 piece rectangular 600 x 500 cm
Surface area 14.3 - 42.4 m2
Height underneath 210 cm
Overall height 385 - 500 cm
Weight 60 - 103 kg


icFrame

aluminium white powder-coated
aluminium graphite grey powder-coated
other colours with additional charge

 International rights for protection
Palazzo® M8, Brand, patent and design registered
