Palazzo® M16

With the hand crank or the optional motor you can open the Palazzo M16 in a very comfortable way. The sunshade canopy closes over tables and chairs. The tough construction is supported by a rotation-proof octagonal pole.

The weatherstrip system allows for individual replacement of single cover panels. And thanks to the optional lighting and/or heating systems you can benefit from a longer outdoor season.

icMaterials and technology: The frame is made of pressed aluminium profiles. Every single part can be replaced individually. The Palazzo M16 has been passed for use by TÜV.

icHow to operate: The sunshade can be opened and closed using the hand crank or the optional motor.
Remote control for the motor drive is available, too.

icWinter storage: Store it on the spot in its protective cover, secured against the wind, or dismantled, in a dry and sheltered place.

icWind safety: The max. wind speed limits as per our separate list apply only if there is a fix ground anchorage.

icAdvertising imprint: Individual imprints on shade roof and/or flounces are possible.

icAttention: The final assembly of the Palazzo M16 has to be carried out on the spot.
icFixing options: Fixing options: 580 kg base (12 concrete slabs) with support tube, ground socket with tip-over hinge, various mounting plates with tip-over hinge allowing a whole lot of different mounting methods.

icAccessories: Protective cover with zip and rod, curtain, rain gutter.

icElectric accessories: Motor drive with control unit, remote control for motor drive, anemometer, key switch (surface or flush mounted). Electric kit, 400 V (3PNE), 13 A for lighting 230 V, 4 x 16 W, and/or radiant heater 1500 W, 230 V, 6.5 A (max. 4 radiant heaters for each sunshade).
Pole profile 580 kg shade base
(12 concrete slabs), support tube 		Ground socket tip-over hinge Mounting plate, tip-over
hinge
Example: Mounting plate
special, for installation
height 50 – 149 mm,
tip-over hinge 		Protective cover Rain gutter of polyester fabric PVCcoated on both sides Curtain
Control unit, motor
drive, key switch 		Control unit, motor drive,
key switch, anemometer		 Remote control,
key switch		 Electric kit

Lighting
Heat transmission,
max. 4 pieces per sunshade


icMaterial qualities and colours

 Material class 5
100 % acrylic approx. 300 g/m2 colours 500 - 699
Sun protection factor UPF 50+

icSizes and weights

12 piece round ø 700 cm
16 piece round ø 750 / 800 / 850 / 900 cm
12 piece square 600 x 600 cm
16 piece square 650 x 650 / 700 x 700 cm
12 piece rectangular 600 x 500 cm
14 piece rectangular 700 x 500 / 700 x 600 cm
Surface area 30 - 62 m2
Height underneath 230 cm
Overall height 480 - 582 cm
Weight 140 - 254 kg

The segments are individually pulled over the rod by means of weatherstrips. If the shade becomes dirty or damaged, the individual segments or shade weatherstrips can be replaced without disassembling the shade.

icFrame

aluminium white powder-coated

International rights for protection
Palazzo® M16, Int. Patents reg.
