Castello® M4

The construction with rotation-proof groove profi les on the pole makes the Castello M4 particularly tough. The sunshade canopy can be easily opened over tables and chairs and offers plenty of protection even when it's pouring. You can tauten the cover with the ajustable rod extensions. The optional lighting and/or heating create a cosy atmosphere at night.

icMaterials and technology: The frame is made of seamless anodized or powder-coated aluminium
profiles, the slide and the crown are made of Rilsan-coated aluminium. The steel parts are corrosion-resistant
and the tautening lever can be secured by means of a padlock.

icHow to operate: The telescopic principle allows for quick opening and closing by means of the slide and tautening lever.

icWinter storage: Store it on the spot in its protective cover, secured against the wind, or dismantled, in a dry and sheltered place.
icWind resistance:The max. wind speed limits as per our separate list apply only if there is a fix ground anchorage.

icAdvertising imprint: Individual imprints on sunshade cover and/or flounces are possible.
icFixing options:180 kg base and slabs, 230 kg base (4 concrete slabs) with support tube, 430 kg base (8 concrete slabs) with support tube, ground socket and support tube with centering device, various mounting plates
with support tube allowing a whole lot of different mounting methods.

icImportant: For the sunshade sizes of Ø 350 cm and 300 x 300 cm you need a base weight of 120 kg
and for the sizes of Ø 400 cm and 350 x 350 cm one of 180 kg.

icAccessories: Protective cover, rain gutter, curtain.

icElectric accessories: Electric kit, 400 V (3PNE), 13 A for lighting 230 V, 2 x 11 W and/or radiant heater
1500 W, 230 V, 6.5 A (max. 4 radiant heaters for each sunshade).
Pole profile
 180 kg shade base with support tube and slabs
230 kg shade base (4 concrete slabs), 430 kg shade base (8 concrete slabs), support tube
Ground socket,
support tube with
centering device
Example: Mounting plate special, for installati
on height 150 –350 mm, support tube
Rain gutter of polyester fabric PVC-coated on both sides
Courtain
Electric kit
Lightning
Heat transmission,
max. 4 pieces
per sunshade

icMaterial qualities and colours

Material class 5
100 % acrylic approx. 300 g/m2 colours 500 - 699
Sun protection factor UPF 50+

icSizes and weights


8 piece round ø 350 / 400 / 450 / 500 / 550 / 600 cm
8 piece square 350 x 350 / 400 x 400 / 450 x 450 / 500 x 500 cm
8 piece rectangular 400 x 300 / 450 x 350 / 500 x 400 cm
Surface area 8.7 - 25 m2
Height underneath 200 cm
Overall height 340 - 435 cm
Weight 35 - 62 kg

icFrame

aluminium white powder-coated
aluminium anodized natural

International rights for protection
Castello® M4, Design reg. DM/044 957, DM/035 353
