Sunwing® C+

Be it round or square, the Sunwing C+ puts everybody in the shade by offering protection against UV rays according
to Australian standards. It draws its modern look from the design without flounces. The roof can be easily and comfortably tilted on both sides up to 90° with the crank and the integrated tilting rod. The roof cover is replaceable, and the flexible rod ends retension it automatically.

Materials and technology: The supporting elements and the roof frame are made of graphite grey
powder-coated aluminium profiles.

How to operate: You can open and close the Sunwing C+ with the hand crank. The crank mechanism is self-locking. With the tilting rod you can tilt the shade roof on both sides up to the vertical position of 90°, in steps of 18°.

Winter storage: Store in the protective cover in a dry place sheltered from the wind. Thanks to the pole in two parts and the telescopic supporting arm it is possible to fold up the sunshade in a practical and space-saving manner. A very small storage space will do.

Advertising imprints: Individual imprints are possible.

Fixing options: Concrete base, granite base, base with castors, base with slabs, ground socket with connecting tube, wall console with support tube.

Accessories: Protective cover with zip and rod, optional rechargeable battery light Osyrion.

Sizes and weights

8 piece round	ø 300 cm / 330 cm
8 piece square	260 x 260 cm
Height underneath	200 cm
Max. height	272 cm
Weight	approx. 18 kg

Frame

aluminium graphite grey powder-coated

International rights for protection
Sunwing® C+, Int. Patents reg. U.S. No. 6,014,980, CH-Patent pend.
